Square Block HGH25CA Guide Block Linear Ball Bearing , Linear Slide Bearings 23x48x40mm
2025-09-16
Product Overview
The HGH25CA Linear Guide Block is part of a professional-grade linear rail system built to provide smooth, precise, and low-friction linear movement. It features a square-type block design that allows for greater load capacity and rigidity, making it suitable for demanding environments and high-precision applications.
Product Specifications:
Model: HGH25CA
Type: Square block linear guide carriage
Dimensions: 23mm height × 48mm width × 40mm length
Structure: Four-row recirculating ball bearing design
Material: High-quality bearing steel with corrosion-resistant treatment
Compatibility: Designed for 25mm linear guide rails (HG/HIWIN-compatible)
Key Features
High load capacity in all directions (radial, reverse radial, and lateral)
Smooth and silent operation due to precision-ground raceways
High rigidity thanks to the square-block profile
Preloaded design for zero backlash and greater accuracy
Easy installation and maintenance with standard mounting holes
Interchangeable with global brands like HIWIN, PMI, THK (same dimensions)
Ideal Applications
The HGH25CA square linear block is engineered for a broad range of mechanical and industrial uses, including:
CNC milling and engraving machines
3D printing and additive manufacturing platforms
Precision robotics and pick-and-place systems
Automated assembly lines and inspection systems
Packaging machinery and factory automation equipment
Its compact size and heavy-duty construction make it ideal for space-constrained systems that still demand high accuracy and durability.
Market Demand & Reliability
As automation continues to grow across manufacturing sectors, the demand for reliable and precise linear motion components is at an all-time high. The HGH25CA meets this demand with industrial-grade reliability, a cost-effective price point, and wide compatibility with existing systems.
Its robust design ensures long service life, even in 24/7 operation cycles, reducing downtime and maximizing productivity.
もっと見る

WR 20mm HGH20HA Linear Ball Bearing Linear Guideways 20x44x30mm
2025-09-16
Product Overview
The WR HGH20HA Linear Guideway is a 20mm-width linear bearing system with dimensions 20x44x30mm. It uses high-precision steel ball circulation within a hardened steel track, allowing for smooth and precise linear motion under heavy loads.
Core Features:
Model: HGH20HA (high profile, square-type block)
Size: 20mm rail width / 44mm block width / 30mm block height
Ball-type linear bearing system for high accuracy and repeatability
Four-row ball circulation design for improved load distribution
Compact form factor suitable for small-to-medium-sized equipment
Corrosion-resistant materials for extended lifespan
Industrial Applications
The WR 20mm HGH20HA linear guideway is suitable for a wide range of industrial and mechanical systems, including:
CNC machinery and routers
3D printing platforms
Semiconductor fabrication equipment
Automated assembly lines
Packaging and labeling machines
Precision inspection systems
Its compact size and robust load-bearing design make it a preferred solution for applications requiring space-saving installation and high-speed motion with minimal deflection.
Built for High-Performance Environments
With its high load capacity and excellent rigidity, the HGH20HA is engineered to handle both radial and lateral forceswith minimal vibration. This results in:
Greater operational stability
Reduced maintenance needs
Higher equipment uptime
Enhanced machining accuracy
Available with a compatible 20mm rail system, this guideway can be easily integrated into existing or custom-built motion control platforms.
Market Impact
As industries continue to automate, demand is rising for compact, high-precision linear motion components. The WR HGH20HA offers an affordable yet durable solution for OEMs, system integrators, and factory automation specialists seeking to build or upgrade their motion systems.
Its compatibility with global standard dimensions also ensures easy replacement and cross-brand integration.
もっと見る

Ball Bearings for Machines & GQZ Solution
2025-09-15
Why are ball bearings used in machines? They solve three core mechanical challenges, making them indispensable for nearly all equipment with moving parts—from daily bicycles and household washing machines to industrial turbines and precision medical devices (like MRI scanners). Patented in 1869 by engineer Jules Suriray, this small component has since reshaped the efficiency of mechanical operations worldwide.
A standard ball bearing relies on five key parts working in perfect sync: High-strength alloy steel balls (the "rolling core") cut friction; a low-friction cage (made of engineering plastic or brass) keeps balls evenly spaced to avoid collisions; inner and outer rings link static and moving components (e.g., a motor shaft and its housing); and a dust cover seals lubrication while blocking dust and debris. A tiny "internal clearance" is also designed to prevent jamming when parts expand from heat during operation.
Diagram of a standard ball bearing labeling its five core components and their roles
Their three pivotal functions make them irreplaceable:
Friction reduction: They turn energy-wasting sliding friction (e.g., between a car’s crankshaft and piston) into low-resistance rolling friction, cutting wear, heat buildup, and energy loss—cars use them to lower CO₂ emissions, while bikes feel lighter to ride.
Component connection: Acting as a "mechanical joint," they link independent static and moving parts (like a bike’s fork and wheel) without direct contact, ensuring stable motion and reducing mutual abrasion.
Load bearing: Different designs fit varied needs—self-aligning bearings handle slight axis misalignment for textile machines, while heavy-duty variants carry up to 50% of their static load, ideal for excavators or crane hooks.
Common types match specific scenarios: Radial bearings handle forces perpendicular to the axis (e.g., water pump impellers); angular contact bearings bear both radial and axial forces (e.g., machine tool spindles); linear bearings enable one-way sliding (e.g., printer paper guides). These variants cut maintenance costs and ensure precision for sensitive gear.
GQZ bearings applied in home appliances (washing machine drums) and heavy industry (turbine shafts)
For reliable, long-lasting performance, GQZ bearings stand out. Crafted with high-quality materials and precision manufacturing, they excel in low friction, stable connection, and strong load-bearing—perfect for everything from small home appliances to large industrial machinery. Choose GQZ bearings to keep your equipment running smoothly and efficiently.
もっと見る

ボールベアリングの製造プロセスについて学ぶ
2025-09-08
ボールベアリングがどのように作られるか疑問に思ったことはありますか?
原材料から完成品までの全工程を直感的に理解できるビデオをご覧ください:
材料の選択:「ボールベアリングは何でできているのか?」という疑問に答えます。ほとんどの場合、硬度と耐摩耗性のために高炭素クロム鋼が使用されます。特殊な用途には、ステンレス鋼(耐腐食性)またはセラミック(高温)ボールベアリングが使用されます。原材料の品質が重要です。鍛造と成形:
鋼を加熱し、荒い内輪/外輪とボールに鍛造し、基本サイズに機械加工します。これは構造的完全性のために重要です。熱処理:
部品を加熱し、焼き入れ(硬化)し、焼き戻して応力を軽減します。これは、ボールベアリングを長持ちさせるために不可欠です。研削:
多段階研削により、部品をミクロンレベルの精度に研磨し、スムーズな動作を保証します。組み立て:
クリーンルームで行われ、リング、ボール、ケージを組み込みます。位置ずれは許されません。潤滑:
グリースまたはオイルを使用して摩擦を減らし、異物をブロックします。品質テスト:
検査、寸法チェック、性能テストにより、コンプライアンスを確保します。ボールベアリングは、自動車、産業機械、家電製品、航空宇宙で使用されています。
GQZベアリングは、
上記の製造プロセスのすべてのステップを厳密に遵守し、原材料の純度と組み立て後の性能に関する追加の品質チェックも行っています。高度な研削技術を使用して超高精度を実現し、特殊なシナリオ(高負荷産業機械や腐食しやすい海洋機器など)向けのカスタマイズされたソリューションを提供し、すべての製品がISO 9001規格に適合しています。
自動車のトランスミッションシステム、精密工作機械、家電製品のモーターなど、
GQZベアリングは、信頼性に優れた耐久性と高性能のオプションを提供します。
もっと見る

ボール ベアリング は 摩擦 を 軽減 する の は どう です か
2025-09-01
ボールベアリングは、高い摩擦係数を持つ滑り摩擦を、はるかに低い摩擦係数を持つ転がり摩擦に置き換えることで摩擦を最小限に抑えます。スムーズで効率的な動きを実現する仕組みは次のとおりです。
1. 転がり運動が滑り運動に取って代わる
互いの表面が擦れ合う(大きな摩擦が発生する)代わりに、ボールベアリングは滑らかな転がりボールを使用して、表面が互いに転がるようにします。この転がり作用は、滑りよりも劇的に効率的で、はるかに少ない抵抗を生み出します。
2. 低摩擦要素としてのボール
ボール自体が「転がり要素」として機能します。これらは、2つの主要な可動面(レースウェイと呼ばれる)を分離し、大きなコンポーネント間の直接的な接触を最小限に抑えるため、運動点での摩擦が大幅に軽減されます。
3. 精密機械加工+潤滑
機械加工: レースウェイとボールは、超高精度と完全な真円度に機械加工されています。表面も高度に研磨されており、スムーズな回転を確保し、摩擦トルク(回転に対する抵抗)を低減します。
潤滑: ほとんどの高品質スチールボールベアリングは、潤滑剤(低トルクオイルやグリースなど)に依存しています。これらは、ボールとレースウェイの間に薄い膜を作り、金属同士の接触を減らします。シールドベアリングは、低摩擦グリースで事前に潤滑されており、オイル膜を維持し、接触点からの熱を放散し、早期故障を防ぎます。
4. スムーズな動作のための荷重分散
ボールベアリングは、可動面を分離し、荷重を均等に分散します。これにより、ラジアル(横方向)力とアキシアル(スラスト)力の両方をサポートしながら、スムーズな回転運動が可能になります。
用途と実際の例
ボールベアリングは、無数のシステムで低摩擦運動を可能にします。主な例を以下に示します。
自動車のホイールハブ: 車のホイールハブでは、ボールベアリングにより、ホイールが車軸に対して滑るのではなく、車軸の周りを回転します。これにより摩擦が劇的に減少し、重い車両でもスムーズに動き、熱や摩耗も軽減され、時間の経過とともに車軸が損傷するのを防ぎます。
電動ドリルチャック: 電動ドリルの回転チャックは、ボールベアリングを使用して、モーターからドリルビットにトルクを最小限の摩擦で伝達します。これにより、ビットが高速かつスムーズに回転し、ユーザーはドリルが過熱することなく、硬い材料に穴を開けることができます。
農業機械(コンバインハーベスター): コンバインハーベスターの回転部品(オーガーやリールアームなど)のボールベアリングは、これらのコンポーネントが作物や穀物を通過する際の摩擦を減らします。これにより、機械は長時間、エネルギー損失を少なくして動作し、燃料消費量と部品の摩耗を削減できます。
ボールベアリングがない場合のコスト
ボールベアリングがないと、滑り摩擦が支配的になります。たとえば、ベアリングのない固定シャフト上の車のホイールは、金属が金属に擦れ合い、大きな摩擦を引き起こし、動きを停止させ、急速な摩耗、熱、騒音につながります。
信頼性の高い低摩擦性能のためのGQZベアリング
信頼性の高い低摩擦ソリューションについては、GQZベアリングは、精密に設計されたボールベアリングを提供しています。研磨されたレースウェイと最適な潤滑適合性により、GQZベアリングは、自動車から農業まで、さまざまな業界でスムーズな動き、摩耗の低減、および機器の長寿命を保証します。
